Standard - any Ø - medium

Quick Overview

Gooseneck/compression strut unit for use with any round mast and suitable for M, 10R and similar size boats.


Body length is 60 mm for the standard version. 50 mm body length available as specified for GRUNGE and TRANCE as a non-standard option.


Choose a boom/strut connector for either 12 or 14 mm Ø main boom.

Product code. 010

Availability: In stock

£42.00

* Required Fields

£42.00

Standard - any Ø - medium

More Views

Details

Gooseneck/compression strut unit for use with any round mast and suitable for M, 10R and similar size boats. The metal body of the gooseneck fits snugly onto a mast with any diameter between 8 and 14 mm and ensures a secure and perfectly aligned fit for this key item of the boat's rig.

Body length is 60 mm for the standard version. 50 mm body length available as specified for GRUNGE and TRANCE as a non-standard option.

The normal boom end fitting has an external diameter of 8 mm to fit our 10 mm CF tube. Select the diameter of the main boom to enable us to provide the correct size attachment to the strut. To avoid having to cut and join the main boom for TRANCE rigs, an alternative boom end fitting is available.

PDFDownloadable Document

Not quite what you need?

There are too many possible variations for our goosenecks to list them all as individual products. But you can specify a custom gooseneck from all the available options by going to product page custom gooseneck ref.0-GNK-M-10R.

Axis alignment

The design of the gooseneck body ensures it is aligned with the mast perfectly. If the effect of a tilted axis gooseneck is required (also known as adjustable axis gooseneck, variable axis gooseneck) then it is a simple matter to place a packer of the required thickness under one end of the gooseneck body before it is fixed to the mast tube. Use deck patch material or other self-adhesive material to achieve this. 1.0 mm thickness will tilt the axis by 1 degree. One layer of SAILSetc deck patch material will tilt the axis by 0.1 degree.

Kicking strap is the English language term used for the adjustable connection between the lower end of the gooseneck and the boom. It is also known as a vang. Compression strut for a boom also known as a gnav.

010-12, 010-14, 010-ANY

Gooseneck, vit de mulet, lümmelbeschlag, zwanehais, svanehais, snood de attacco, pescante arbotante, mangual.
